Bay and Bow Windows




Bay and Bow windows create opportunities to complement any home's decor. From hanging plants to window seats, these three dimensional additions allow for many options. There are literally hundreds of options with configurations and decorative enhancements to meet your home's specific needs or style. These windows can be made using double hung or casement flankers and picture window or fixed lite casement center units.
Features
Options
Data
Downloads

Features

  • Bay windows may be 30 or 45 degrees
  • Bow windows are 15 degrees
  • All units come completely assembled and ready for installation
  • Cable system is mandatory
  • Double hung flankers are considered standard
  • Screens are included on all operable flankers
  • All units include insulated glass
  • 1" Birch head and seat board is standard
  • Available colors are white and almond
  • Transferable Limited Lifetime warranty

Options

Exterior Color Options

  • Hunter Green (Paint)
  • Dark Chocolate (Paint)
  • Terratone (Paint)
  • Clay (Paint)
  • Brick Red (Paint)
  • Gray (Paint)
  • Bronze (Paint)
  • Tan (Paint)
  • Bronze Laminate Finish (available on white window - 8900 series only.)

Note: ONLY use mild, water based household cleaners on painted products and rinse immediately with water. See full cleaning instructions for details.

Interior Color Options

  • Light Oak
  • Dark Oak
  • Cherry

Note: Woodgrain finishes on 8900 Series Wwindows available on white exterior only.

Product Sizes

  • Custom sized on 1/8'' increments

Frame Options

  • Block frame

Decorative Glass Options

  • Polished beveled glass available in Colonial Diamond Double Prairie and Florentine patterns
  • Leaded glass also available (in picture windows only)

Glass Options

  • Low-E
  • Low-E with Argon Gas
  • Ultra Low-e with Argon Gas (may be required for Energy Star rating)
  • Tempered
  • Obscure
  • Double Strength
  • Krypton Insulation Package

Grid Styles

  • 5/8'' or 3/4'' box grids between the glass
  • 5/8'' or 1'' contoured grids between the glass
  • 1-1/8'' applied SDL

Grid Patterns

  • 5/8" flat and contoured
  • 3/4" flat
  • 1" contoured
  • 1-1/8" Simulated Divided Lite (8900 series only)

Product Hardware

  • Hardware package varies by flanker type. See Double Hung or Casement pages for details

Data

  • Series: Bay and Bow
  • Sash Operation: Double Hung or Casement
  • Frame Material: Vinyl (PVC)
  • Frame Construction: Fusion Welded
  • Exterior Frame Appearance: Beveled
  • Frame Depth: Projection depth varies depending upon width of individual window units
  • Frame Style: Block frame
  • Sill Design: Sloped
  • Glass:
    • 7/8'' Insulated (Double Hung)
    • 3/4'' Insulated (Casement)
  • Divided Lites: flat and contoured grids available between glass and 1-1/8
  • Hardware: Hardware package varies by flanker type. See Double Hung or Casement pages for details
  • Sash Balances: Constant force coil (Double Hungs only)
  • Screen Frame: Color matched extruded aluminum
  • Screen Mesh: 18 x 16 Fiberglass mesh
  • Structural Performance: Performance varies by flanker type. See Double Hung or Casement pages for details
